Open for change.
Expand your charging without lock-in — scale up however you want. Future-proof on your terms.
Fully open standard
Adapt installs without a backplate and is easy to expand — without locking future installations to Waybler's chargers.
Solid electrical connection
With a 16 mm² terminal block, Adapt can be installed easily with a single cable — regardless of how many chargers.
Swedish-built quality
Adapt is developed and manufactured in Sweden, with a durable and elegant aluminium enclosure.
The charger that has it all...
22 kW charging power
Robust enclosure — built to withstand tough environments
Flexible design for different installation types
Dynamic phase selection — efficient load distribution
Multiple connection options
...except one thing.
No lock-in.
Instead, you get an open standard with full freedom.
Fully open.
Inside and out.
While others lock users to their own chargers, we choose the opposite: a fully open standard. Adapt ships OCPP-compatible and installs without backplates.
When it’s time to expand, you can choose whichever chargers and charging service you want — even if we, of course, hope you’ll choose Waybler next time too.
Where does Adapt fit?
Best in class.
In a class of its own.
We've built Waybler Adapt around our philosophy that EV charging should be easy to expand and scale up — instead of locking users to our own system.
| Charging | |
| Charging current | 6-32 A |
| Charging power | 1,4-22 kW |
| Charging socket | Typ 2 |
| Charging mode | Mode 3 |
| Number of outlets | 1 outlet |
| Number of phases | 3-phase, active phase selection |
| Energy metering | MID-approved |
| Earth fault detection | Built-in earth fault detection 30 mA AC, 6 mA DC |
| Earth fault reset | Semi-automatic |
| Locking motor | Yes |
| Charging standard | IEC 61851-1 and EN 62196-2 |
| Electrical connection | |
| Electrical connection | 16 mm² terminal block |
| Grid system | TN grid |
| Voltage | 230 V/400 V |
| Frequency | 50 Hz |
| Number of phases | 1-phase or 3-phase |
| Connection & Enclosure | |
| Material | Aluminium |
| Enclosure rating (IP) | IP 54 |
| Impact rating (IK) | IK10 |
| Operating temperature | -30 °C to +50 °C |
| Mounting | Wall mount Pedestal mount |
| Enclosure lock | Triangle key 10 |
| Standard | IEC 61439-7 |
| Weight | 5,1 kg |
| Dimension | 262 mm × 335 mm × 140 mm excl. outlet 288 mm × 335 mm × 140 mm incl. outlet |
| Communication | |
| Communication protocol | WCP, OCPP 1.6 (2.0.1 support coming) |
| Connections | Wi-Fi, Ethernet, LTE (optional) |
| Modbus | Yes (optional) |
| Energy meter | Visible MID |
| User interface | |
| Authentication | App, RFID (optional) |
| Status | LED (RGB) |
